AR664SCT 8561011

Dimensions 152 x 152 x 102

Dimensions 6 x 6 x 4

Including : Screw cover. Base with 10-32 brass inserts, cover with formed in place PUR gasket and 4 stainless cover screws. Enclosure mounting foot kit. Accessory 10-32 screws for panel mounting.

PC : IP66; IP67; IK09

Product number : 8561011 Download product card

Technical data

Product:

Product nr : 8561011

Description : PC Enclosure

Remarks : Transparent screw cover

Package : 1

Unit : Piece

EAN : 6418074066282

ETIM : EC000261 Enclosure/Switchgear cabinet (empty)

Dimensions :

Height (mm) : 152

Width (mm) : 152

Depth (mm) : 102

Height (inch) : 6

Width (inch) : 6

Depth (inch) : 4

Materials :

Material : Polycarbonate

Base colour : RAL 7035 -light grey

Cover colour : Transparent

Gasket material : Polyurethane

Temperatures :

Temperature °C (short term) : -40 … 140

Temperature °C (continuous) : -40 … 80

Temperature °F (short term) : -40 … 250

Temperature °F (continuous) : -40 … 175

Ratings :

Ingress Protection (EN 60529): IP66IP67

Impact Resistance (EN 62262): IK09

Electrical insulation : Not insulated

Halogen free (DIN/VDE 0472, Part 815) : Yes

UV resistance : UL 508

Flammability Rating : UL 508

Glow Wire Test (IEC 60695): 960 °C

NEMA Class : NEMA 4, 4X, 6, 6P, 12, 12K and 13

Product is connected to following catalogues :

ARCA JIC / AR 664 / AR664SCT

CAD Files

Please note, that we need your permission in order for you to view the CAD files.

Contact

Accessories

AMFL6

6" Mounting Flange Set

ABP66

Painted Steel Back Panel
(124 x 124)

ASPHK6

Swing Panel Kit w/o Panel

ASPK66

Swing Panel Kit incl. Panel

ALBP66

Aluminum Back Panel
(124 x 124)

APBP66

PVC Back Panel
(124 x 124)

ASP66

Aluminum Swing Panel
(153 x 154 x 0)

ADFP66

Dead Front Panel w/ screws
(155 x 157 x 0)

Sample image

Order symbol : AR664SCT

Product nr : 8561011

Description : PC Enclosure

Remarks : Transparent screw cover

EAN : 6418074066282
