ALN 233311 UP
7831380
ALU aluminium enclosure range is designed to house DIN-rail mounted terminal block and various types of sensors.
Dimensions - 230 x 330 x 110
Description : Enclosure. Aluminium
Package : 1
Unit : Piece
EAN : 6418074031549
SSTL number : 3425015
ETIM : EC000261
Ingress Protection : IP66/67 | IK08
Height (mm) : 230
Width (mm) : 330
Depth (mm) : 110
Height (inch) : 9.06
Width (inch) : 12.99
Depth (inch) : 4.33
Material : Aluminum
Gasket material : Silicone
Temperature °C : -50 … 80
Temperature °F : -60 … 175
Ingress Protection (EN 60529): IP66/67
Impact Resistance (EN 62262): IK08
Halogen free (DIN/VDE 0472, Part 815) : Yes
UV resistance : UL 746C
CAD Drawings
- ALN233309B.dwg
- ALN233302C.dwg
- ALN233309B.dxf
- ALN233302C.dxf
- FIBOX ALN_233309B.stp
- FIBOX ALN_233302C.stp
- FIBOX ALN_233309B.x_t
- FIBOX ALN_233302C.x_t
- FIBOX ALN_233309B.zip
- FIBOX ALN_233302C.zip
- 7811380_FIBOX_ALN233311.step
Please note, that we need you permission in order for you to view the CAD files.
ALN 233311 UP
Sample image
Order symbol : ALN 233311 UP
Product nr : 7831380
Description : Enclosure. Aluminium
EAN : 6418074031549
El. number :
- Finland : 3425015
Including : Base with screws for mounting plate/DIN-rail, cover, silicone gasket, stainless steel cover screws.
| Dimensions : | Height | Width | Depth |
|---|---|---|---|
| mm : | 230 | 330 | 110 |
| inch : | 9.06 | 12.99 | 4.33 |
| Materials : | |
|---|---|
| Material : | Aluminum |
| Gasket material : | Silicone |
| Temperatures : | |
|---|---|
| Temperature °C (continuous) : | -50 … 80 |
| Temperature °F (continuous) : | -60 … 175 |
| Ratings : | |
|---|---|
| Ingress protection (EN 60529): | IP66/67; |
| Impact Resistance (EN 62262): | IK08; |
| electrical_insulation : | Not insulated |
| Halogen free (DIN/VDE 0472, Part 815) : | Yes |
| UV resistance : | UL 746C |
| Certificates : | |
|---|---|
| SGSFIMKO_ALU | |
